Optical Splitter and Splitter Box
FBT Splitter 1x4
ABS box type FBT fiber optic splitter, 1x4.
Specifications
| Product | FBT splitter 1x4 |
|---|---|
| Type | ABS box type |
| Operating wavelength | 1310 nm, 1550 nm |
| Connector type | FC, LC, ST, SC and others |
| Cable diameter | 2.0 mm |
| Cable length | 1 meter |
| Order options | FBT or PLC splitter, SM or MM; splitting ratios such as 1x2, 1x4, 1x8, 2x2, 2x4, 2x8; operating wavelength; input and output fiber length and cable diameter; with or without connector (SC, LC, FC, ST ...); steel tube type or ABS box type |
Description
A fiber optic splitter is used to split a fiber optic beam into several beams at a certain splitting ratio. It is an important passive device in passive optical networks (EPON, GPON, BPON, FTTX, FTTH, etc.).
