Fiber Optic Splice Closure
Inline Fiber Optic Splice Closure
Our Inline Fiber Optic Splice Closure provides reliable protection for optical fiber splicing and cable connections.
Specifications
| Cable ports | 6 (3 in / 3 out), 4 × Ø7 mm and 2 × Ø12 mm |
|---|---|
| Splice trays | Up to 6 × OST 038, 24 fibers per tray |
| Capacity | 24, 48, 72, 96, and 144 cores |
| Protection | IP65 dustproof and waterproof |
| Applications | Aerial/hanging, duct, and direct burial |
Description
Our Inline Fiber Optic Splice Closure provides reliable protection for optical fiber splicing and cable connections. Its durable enclosure and sealing gasket help protect internal components from environmental conditions, making it suitable for outdoor applications.
Designed for aerial/hanging, duct, and direct-buried installations, it features 6 cable ports (3 in / 3 out) and supports up to 6 OST 038 splice trays, with a maximum capacity of 144 fibers.
